Quick Details

  • Condition: New
  • Type: Pipe Bender
  • Pipe Material: galvanized sheet
  • Application: Energy Supply Pipe
  • Production Capacity: 1-40m/min
  • Place of Origin: Shanghai, China (Mainland)
  • Brand Name: Metform
  • Model Number: FM-ST01-1500
  • Voltage: 220/380/415/420/440V
  • Power(W): 10KW
  • Dimension(L*W*H): L 3100xW2500xH2850mm
  • Weight: 2500kg
  • Certification: ISO9001:2008
  • Warranty: 12 Months
  • After-sales Service Provided: Engineers available to service machinery overseas
  • product name: metform air duct forming machine
  • application: Air conditioning equipment
  • material: aluminum
  • colour: blue
  • MOQ: 1 set
  • port: Shanghai
  • brand name: Metform
  • country of origin: Shanghai China
  • key word: duct forming machine
  • Availability: 10 sets

Packaging & Delivery

Packaging Details green wood box or in nude
Delivery Time 15 working days

Metform aluminium tube production line

Product Description

 The Metform aluminium tube production line consists Pay-off unit, roller forming unit, rounding unit, cut-off unit and run-out stand. Metform aluminium tube production line is used for making spiral tube of different diameters. Certain strip dies need for different diameter tube as showing left. Metform spiral tube making machine will be supplied with 20 piece of dies, their sizes will be choose when ordering.



Incoming metal sheet:  width137 mm

Strip thickness: GI 0.4-1.2 mm

              Stainless steel 0.3-0.7 mm

              Al: 0.4-1.5 mm

Diameter of tube: 80-1500 mm

Length of tube: Pre-setting length, Automatic control

Feeding Speed: 0-40m/min adjustable



Cut-off unit: Automatic synchronous flying Cutting System,Sawing machine (cut-off could equip Slitter or Plasma too for lower noise and better safety)

Run-out stand: length 4 m as standard accessory

Overall Size:  L 3100×W2500×H2850mm

Weight:  2600KG

Power supply 10 KW

Pneumatic supply 0.4-0.7 MPa, 50 L/min

Rollers are made of SKD1(D3). And the cutting saw is made of High speed steel.

PLC controlled and touch screen operation interface



  Technical parameters about air duct forming machine

Diameter range

Φ80-Φ1500mm

Tube Length

120-8000mm

Thickness of Strip

0.4-1.2mm

Width of Strip

137mm

Strip Speed

1-40/min adjustable

Lockseam

Outside tube,on the inside on request

Control System

PLC automatic control

Electric Power

380V/3PH/50HZ

(Acorrding to customer’s request)

Main Motor Power

5.5kw

Cutting System

Saw cutting

Cutting motor power

4kw

Suitable Material

Galvanized steel,Stainless steel,Aluminum

Weight

About 2500kg

Dimension

2100*2000*2850mm

Packaging & Shipping

 Packaging:

Stable wooden package protects machine from strike and damage.

Wound plastic film keeps machine out of damp and corrosion.

Fumigation-free package helps the smooth customs clearance.

The big size machine will be fixed in container without package.



Shipping:

For LCL, we cooperated with reputable logistics team to send machine to sea port speedily and safely.

For FCL, we get machines to container loading by our skillful workers carefully.

For forwarders, we have professional and long-term cooperated forwarders who can handle the shipment smoothly. Also we would like to have seamless cooperation with your forwarder at your convenience.



Our Services

 A.Warranty : 12 months

B.Engineers available to serve machine overseas

C.Strict factory inspection

D.Complete equipment manual

E.Online instruction

F.Provide all components, spare parts and consumptive material

Company Information

 Metform ( Shanghai) machinery Co., Ltd., located in Songjiang Shanghai, was established in 2004. Metform specializes in design and manufacture of special machine for metal sheet/strip manufacture and forming. We are designers and builders of high quality metal coil processing line. We supply machines with latest available technology, design and innovation in machinery engineering. The main product are spiral tube forming machine, folding machine, Lock forming machine and bending machine etc for air duct, as well as various specification of small 2 high/ 4 high mill, slitting and cut-to-length line. Metform deals and exports a wide variety of machines for metal sheet processing and used Construction equipment too. The promise of Metform is to produce machine with excellent quality, diligently satisfy the customer's need and create value for you by means of our products and service.

Main Products
machinery equipment- seam welding machines, spiral tube forming machines, elbow making machines, roll bending machines, angle steel flat steel volume circle machines, lock formers, hydraulic notching machines, hydraulic combined punching and shearing machine,CNC plasma/laser cutting machine,punch presses, metalworking machines,coil processing machinery, leveling machine,slitting line, cut-to-length lines, rolling mills
FAQ

 •How to get a accurate quotation from us?

provide us the detail of the material such as metal thickness and width,cutting area



• what’s the shipping cost from China to your country?

We can send machine to your port or door address by sea or airplane.

Please kindly tell us your nearest port or address with postcode.

We have reliable shipping agent to insure the safe,convenient and timely delivery.



• How to check imported charges or tax ?

Call your Customer.tell them machine HS code.

Spiral duct forming machine is 8455229090

Press brake and rolling machines are 84622990.

shearing machine is 84623990.

rolling machine is 8455229090

seam welding hs code is 85152900



• Payment terms,MOQ,warranty,FOB...

payment terms 30% down payment with order by T/T,the balance of 70% to be paid on delivery

minimum order quantity:1 set,FOB Shanghai.

delivery time :20days after receipt of formal order and 30% deposit.

warranty:12 months following delivery.

We offer online service 24 hours all day long, Skype, Email etc .

You can contact us any time,if urgently,please call us.



• what’s the package?

 fumigation-free plywood case or without package

• How to operate this machine ?

 video link of our factory .......or we send you the movie directly



• what about commissioning service ?

 we can offer commissioning service,the buyer need to afford plane tickets



• Do you offer teaching&training ?

Training at supplier’s plant



• what’s policy for guarantee and broken parts?

Warranty period of equipment lasts a year, during which the broken parts and spares caused by quality can be offered free.
